High Voltage Capacitor Boost Module 5VTo12V 300VTo1200V

Discover reliable high‑voltage capability with the High Voltage Capacitor Charging Boost Module. Designed as a compact DC‑DC boost converter, this 5V–12V input module steps up to a 280–1200V output range (280–1200V when input is 5V; 400–1200V when input is 6–12V). Ideal for capacitor charging projects and small HV applications, it delivers stable voltage, impressive efficiency, and with built‑in protections to keep your devices safe.

Benefits & Tips

• Efficient power conversion: High energy efficiency minimizes waste while maximizing the utility of your 5V–12V power source.
• Stable output for reliable operation: Consistent voltage helps your devices and experiments run smoothly without interruptions.
• Compact, versatile design: Small footprint and integrated construction fit into tight spaces and portable setups.

Product Specifications

• Brand: ALLOYSEED
• Origin: Mainland China
• Type: Module
• Condition: New
• Power: 5W
• Input voltage: 5–12V (less than 12V)
• Output voltage: 280–1200V at 5V input; 400–1200V at 6–12V input
• Product size: 65.00 × 32.00 × 16.00 mm (2.56 × 1.26 × 0.63 inch)
• Note: The capacitor can be charged; fast charging speed is not supported.
• Important: As a power output module, it is not a sensor. It provides DC output; AC output is limited and not adjustable (around 75V).
• Voltage guidance: The voltage range should be kept below 12V input; the recommended input is 5V.

Package includes:

• 1 × DC-DC Boost Converter

Warnings / Reminders

• Capacitor charging is supported, but avoid attempting fast charging speeds.
• This module is intended for DC output; it is not a sensor.
• When using at higher inputs (6–12V), expect higher HV output (400–1200V). Do not exceed the recommended input voltage.
• Color appearance may vary slightly due to monitor and lighting differences; allow 1–2 cm measuring deviation due to manual measurement.
